Master Switch — Micro Switches 2
Detailed description
Features
Double circuit type of limit switch
Highly rigid construction, consists of intensive plastic and zinccast (Head and cover snugly fit in box)
Small volume, water-proof and oil-proof construction
Built-in basic switch with double spring mechanism, longer mechanical life
Smooth operation with greater OT
Easy-to-wire circuit opening design
Wide variety of actuators, easily use
Product characteristics
Rated Voltage (V) | Noninductive Load (A) | Inductive Load (A) | Inrush Current | |||||||
Resistance Load | Lamp Load | Inductive Load | Motor Load | |||||||
NC | NO | NC | NO | NC | NO | NC | NO | NC | NO | |
125VAC 250VAC 500VAC | 15 15 3 | 3 2.5 1.5 | 1.5 1.25 0.75 | 15 15 2.5 | 5 3 1.5 | 2.5 1.5 0.75 | 30 max. | 15 max. | ||
8VDC 14VDC 30VDC 125VDC 250VDC | 15 15 6(2) 0.4 0.2 | 3 3 3 0.4 0.2 | 1.5 1.5 1.5 0.4 0.2 | 15 10 5 0.05 0.03 | 5 5 5 0.05 0.03 | 2.5 2.5 2.5 0.05 0.03 | ||||
